Vigor1220 Series

Vigor1220 Series: The Next-Generation 10G XGS-PON Router for SMBs and ISPs


Vigor1220 Series: The Next-Generation 10G XGS-PON Router for SMBs and ISPs with this router

The DrayTek Vigor1220 Series is a cutting-edge XGS-PON VPN router engineered to deliver symmetric 10G fiber connectivity while integrating advanced routing, robust security, and integrated VPN capabilities for modern SMB and ISP environments.

As fiber networks evolve toward next-generation standards, the Vigor1220 Series bridges the gap between high-speed access and enterprise-grade security. Whether you are an ISP deploying edge infrastructure or a small- to medium-sized business requiring multi-gigabit performance, this series offers a unified platform for secure, high-performance connectivity from the fiber access point to the network edge.

Unmatched 10G Connectivity and Flexible Deployment

The core strength of the Vigor1220 lies in its 10G XGS-PON WAN interface, which provides symmetric upload and download speeds essential for modern cloud applications and data-intensive workflows. Beyond the primary fiber connection, the router ensures deployment flexibility through a comprehensive array of additional interfaces:

• 10GbE and SFP+ Ports: Includes a 10GbE RJ-45 port (configurable as LAN or WAN) and a 10GbE SFP+ slot for secondary fiber or copper uplinks.
• Multi-Gig LAN Support: Features 1× 2.5GbE LAN, 3× 1GbE LAN, and 1× 10GbE LAN/WAN to support mixed-speed network environments.
• USB Backup: Two USB 2.0 ports allow for 3G/4G modem backup or connection to external storage, ensuring redundancy during primary link failures.

This flexible port configuration makes the device ideal for FTTH (Fiber to the Home) deployments and ISP/MSP edge scenarios where network topology varies significantly.

Wi-Fi 7 Performance on the Vigor1220be

The series includes two distinct variants to suit different needs: the standard Vigor1220 and the Vigor1220be, which features built-in Wi-Fi 7 (802.11be) wireless capabilities. The Vigor1220be represents a significant leap in wireless technology, offering:

• Multi-Link Operation (MLO): Simultaneously aggregates connections across 2.4 GHz and 5 GHz bands to reduce latency and increase throughput.
• Zero-wait DFS: Dynamically switches channels to avoid congestion without waiting, ensuring seamless performance.
• Blazing Speeds: Delivers up to 1,376 Mbps on the 2.4 GHz band and 5,764 Mbps on the 5 GHz band.

For organizations requiring a single device that handles both 10G fiber access and the latest wireless standards, the Vigor1220be eliminates the need for a separate access point.

Enterprise-Grade Security and VPN Capabilities

Speed is critical, but security is non-negotiable. The Vigor1220 operates on the new DrayOS 5 operating system, which integrates powerful management and security features like Identity & Access Management (IAM) and Virtual Controller for centralized device management. Key security features include:

• VigorShield: Utilizes URL and IP reputation databases to block malicious sites and prevent threats before they reach the network.
• SPI Firewall: Features Stateful Packet Inspection with URL/keyword filtering, category blocking, and application-level blocking.
• VPN Capacity: Supports up to 50 concurrent VPN tunnels with an IPsec throughput of approximately 500–540 Mbps.
• Protocol Support: Compatible with IPsec, SSL, and OpenVPN for secure remote office connections and teleworker access.

The router also supports Dual-WAN configurations with Load Balancing and Failover, ensuring business continuity even if the primary 10G fiber link experiences an outage.

Performance Metrics and Target Use Cases

Built for high-performance network environments, the Vigor1220 delivers a 9.3 Gbps NAT throughput and supports up to 60,000 NAT sessions. This performance profile makes it suitable for three primary use cases:

Conclusion

The DrayTek Vigor1220 Series redefines what is possible for SMBs and ISPs seeking to capitalize on 10G fiber infrastructure. By combining symmetric XGS-PON connectivity, Wi-Fi 7 wireless performance (on the be model), and DrayOS 5 security into a single platform, it eliminates the complexity of multi-device setups. For organizations ready to upgrade their network edge to handle the demands of modern data traffic, the Vigor1220 is a robust, future-ready solution.
